Waterproof Backup Camera 170 Degree Angle License Plate Pack of 2 Y356
Waterproof Backup Camera 170 Degree Angle License Plate Pack of 2 Y356
170 degree visible range works great with the blind spot
Package includes:1 x CCD Car Camera,1x user manual,1 x 6M video cable,1 X power supply cable
Route the cable from tailgate to front dash, connect to display with universal RCA connector, you may need additional adapter (not included) if to connect factory radio
Remark:This camera do not work well with original factory display/monitor, will work well with aftermarket display/monitor .Please check the dimension for fitting to your number plate light recess before purchasing
This product could fit for all below models as expected:
Mercedes-Benz E-Klasse E-Class E320 from 2007 (choose No.1)
Mercedes-Benz E-Klasse T-model S211 Kombi (choose No.1)
Mercedes-Benz C-Klasse W203/Nur Kombi T-model-Touring (choose No.1)
Mercedes-Benz SLK R171 Cabriolet(Bj 2004-2011) (choose No.1)
Mercedes-Benz E-Klasse W211 Limo/W300 (choose No.1)
Mercedes-Benz C/CLS Klasse C219 W219/T-model S203/W203/W211/S211 Kombi Limousine (choose No.1)
Mercedes-Benz CLS Klasse CLS550/CLS300/320/350/500/E230/320CDI (Bj 2004-2011) (choose No.2)
Mercedes-Benz C-Klasse W203 Limo (choose No.3)
Mercedes-Benz C-Klasse W203 C240 4 matic 2004;W203/200 CDI Limousine (choose No.4)
Mercedes-Benz SL R230 Cabriolet (choose No.4)
Mercedes-Benz C-Klasse CL203 W203 Coupe (choose No.4)
Mercedes-Benz CLK W209/A209/C209 Cabrio (Bj 2004-2011) (choose No.4)
Chrysler Crossfire Roadster (choose No.4)
Technique Parameter:
1. TV system: NTSC (if you need PAL, please leave a message)
2. Resolution: 480/520 TV lines
3. Lens angle:170°
4. S/N ratio: more than 48db(AGC-OFF)
5. Video Color: Colorful
6. Video Output: 1.0Vp-p,75Ω
7. Image Device: 1/4 inch color
8. Sensing area: 5.78 x 4.19mm
9. Sync. system: internal
10.Power supply: DC 12V
11,White Balance: Auto
12.Waterproof Class: ip 66
13.Effective pixels: 628 x 586 Pixels
14.Electronic Shutter: 1/60-1/10000 seconds
15.Current Consumption: ≤150mA
16.Current consumption: 90mA Max
17.Storage temperature:-40°C to +60°C, RH95% Max
18.Minimum illumination:0.3Lux/F1.2
19.Operating Temperature:-30°C to +50°C, RH95%
Package Content:
1 x Car CCD Camera
1 x 6M video cable
1 x 1M power cable
1 x User Manual
